| Size | 92.5mm×92.5mm×38mm(Excluding attachments) |
| Class of protection | IP67 |
| RS232 | 115200bps(Default) |
| RS485 | 115200bps(Default) |
| RJ45 | 10M/100M adaptive |
| Agreement | ISO18000-6B/6C EPC C1G2 |
| Operating frequency | CHN：920MHz~925MHz FCC：902MHz~928MHz ETSI：865MHz~868MHz Other multinational frequency standards (customizable) |
| RF output power | 23dBm±1dBm(MAX) |
| Power regulation | 1dBm step |
| Channel bandwidth | <200KHz |
| Frequency stability | ≤±10ppm |
| Recognition speed | >400 times/second (recognition count ≠ recognition quantity, multiple tags can be read at once) |
| Recognition distance | 0cm～120cm(depending on the label or the environment) |
| Sensitivity | ≤ -80dBm |
| Working mode | Instruction card reading mode/automatic card reading mode |
| Functional Features | Support online upgrade Support tag data filtering RF output power adjustable Fixed frequency/frequency hopping optional Support black and white lists Support card reading indicator light |
| Power supply | 12~24V/POE |
| Working power consumption | 8.5W |
| Standby power | 0.6W |
| Operating Temp | -25℃～+80℃ |
| Storage Temp | -40℃～+85℃ |
| Humidity | 5%RH～95%RH(Non condensing state) |
| Atmospheric pressure | 86kPa~108kPa |
