| Size | 171.5mm×69mm×9.25mm |
| Working voltage | DC +4.5V~+6V |
| Standby current | <20mA |
| Working current | 5V power supply, maximum emission 35dBm, peak operating current around 3000mA |
| RF Power | 0~33dBm (± 1dBm) adjustable |
| Stepping | ±1dBm |
| Receiving sensitivity | ≤-85dBm |
| Label RSSI | Support |
| RFID | Based on Impinj E710 chip Based on Impinj R2000 chip (optional) |
| Agreement | ISO/IEC 18000-6B，6C/EPC C1Gen2、C2Gen2，GB/T 29768-2013(optional), GJB 7377.1(optional) |
| Operating frequency | CHN：920MHz～925MHz FCC：902MHz～928MHz ETSI：865MHz～868MHz Other multinational frequency standards (customizable) |
| Heat dissipation | External heat sink air cooling |
| Interface | TTL UART interface (baud rate: 115200bps, data bits: 8, stop bit: 1, parity bit: none, flow control bit: none) |
| Antenna interface | 16-channel SMA interface |
| Connecting wire | 15PIN 1.25mm spacing cable |
| GPIO | 2-channel input, 2-channel output (3.3V level) |
| Operating Temp | -25℃～+70℃ |
| Storage Temp | -45℃～+85℃ |
| Humidity | 5%RH～95%RH（non-condensing） |
