| Frequency | 902-928MHz |
| Gain | 9dBi |
| Lobe width | Hor:90° Ver:90° |
| Polarization mode | Circular polarized |
| Standing-wave ratio | ≤1.4 |
| Front-to-back ratio | ≥20 |
| Impedance | 50Ω |
| Maximum input power | 100W |
| Lightning protection | DC grounding |
| Joint type | SMA Interface(optional) |
| Antenna size | 260*260*30mm |
| net weight | 1.1kg |
| Packaging size | 29*29*8cm |
| Gross weight | 1.68kg |
| Material | ABS |
| Colour | White |
| Install | Hanging ears Install(optional) |
| Working Temp | -20-60℃ |
| Class of protection | IP65 |
